WL-3068 unique fire stop products system and 49 similar items

WL-3068 unique fire stop products system split sleeve 350 kcmil, 150 pair, 12 awg, fabricated steel sleeve. were are selling the threaded sleeve only with the square metal around it wL3068 Wall Assembly — The fire-rated gypsum wallboard/stud wall assembly shall be constructed of the materials and in the manner specified in the individual U300 or U400 Series Wall and Partition Designs in the UL Fire Resistance Directory and shall include the following construction features: A. Studs — Wall framing may consist of either wood studs or steel channel studs. Wood studs to consist of nom 2 by 4 in. lumber spaced 16 in. OC. Steel studs to be min 3-5/8 in. wide and spaced max 24 in. OC. B. Gypsum Board* — Two layers of nom 5/8 in. thick gypsum wallboard, as specified in the individual Wall and Partition Design. 2. Cables — Aggregate cross-sectional area of cables in Split Sleeve to be min 8 percent to max 36 percent of the aggregate cross-sectional area of the Split Sleeve. Cables to be rigidly supported on both sides of wall assembly. Any combination of the following types and sizes of copper conductor cable may be used: A. Max 350 kcmil single conductor Type XHHW power cables; cross-linked polyethylene (XLPE) insulation. B. Max 150 pair No. 24 AWG conductor telecommunication cables; polyvinyl chloride (PVC) insulation and jacket materials. C. Max No. 12 AWG multiconductor Type TC power and control cables; Type XHHW conductors XLPE insulation with XLPE or PVC jacket. 3. Firestop System — The firestop system shall consist of the following: A. Firestop Device* — Threaded steel sleeve halves incorporating split nuts and split washers sized to fit the specific diam of the opening. Device shall be installed around cables in accordance with the accompanying installation instructions. Device provided in nom 1, 2 and 4 in. sizes. Max diam of opening in wall for 1, 2 and 4 in. size devices are 1-1/4, 2-7/16 and 4-1/2 in., respectively. UNIQUE FIRE STOP PRODUCTS INC — Split Sleeve B. Packing Material — Min 1 in. thickness of min 4.0 pcf mineral wool batt insulation firmly packed into Split Sleeve as a permanent form. Packing material to be recessed from each end of Split Sleeve as required to accommodate the required thickness of fill material. C. Fill, Void or Cavity Material* — Caulk, Sealant or Putty — Min 1 in. thickness of fill material applied within the Split Sleeve, flush with both ends. 3M COMPANY — CP 25WB+ Caulk, MPS-2+ Putty or FB-3000 WT Sealant * Indicates such products shall bear the UL or cUL Certification Mark for jurisdictions employing the UL or cUL Certification (such as Canada), respectively.
