Features: 4K resolution, H.265+, True 120dB WDR, IP67, Matrix IR 2.0, LTS-Connect cloud service and APP for remote management and views of devices, built-in microphone, 256GB SD card storage High quality imaging with 4K resolution Efficient H.265+ compression technology Clear imaging even with strong back lighting due to 120dB WDR Water and dust resistant (IP67) Matrix IR 2.0: advanced infrared technology with long IR range LTS-Connect cloud service and APP for remote management and views of devices Built-in microphone for real-time audio security Support up to 256 GB SD card storage Camera Image Sensor 1/2.5" Progressive Scan CMOS Min. Illumination 0.01 Lux @ (F2.0, AGC ON) Shutter Speed 1/3 s to 1/100,000 s Slow Shutter Yes Wide Dynamic Range 120 dB Day Night ICR Cut Angle Adjustment Pan: 0 to 360, tilt: 0 to 75, rotate: 0 to 360 Lens Lens Type FOV 2.8 mm, horizontal FOV 102, vertical FOV 53, diagonal FOV 123 Aperture F2.0 Lens Mount M12 Illuminator IR Range Up to 98ft(30 m) Wavelength 850 nm Smart Supplement Light Yes Video Max. Resolution 3840 2160 Main Stream 50Hz: 12.5 fps (3840 2160, 2560 1440, 1920 1080, 1280 720) 60Hz: 15 fps (3840 2160, 2592 1944, 1920 1080, 1280 720) Sub Stream 50Hz: 25 fps (640 480, 640 360) 60Hz: 30 fps (640 480, 640 360) Video Compression Main stream: H.265+/H.265 Sub-stream: H.265/MJPEG Video Bit Rate 32 Kbps to 16 Mbps H.265 Type Main Profile H.265+ Main stream supports Bit Rate Control CBR/VBR Scalable Video Coding (SVC) H.265 supports Region of Interest (ROI) 1 fixed region for main stream and sub-stream Audio Environment Noise Filtering Yes Audio Sampling Rate 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Audio Compression G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC Audio Bit Rate 64 Kbps(G.711 ulaw)/64 Kbps(G.711 alaw)/16 Kbps(G.722.1)/16 Kbps(G.726)/32-192 Kbps(MP2L2)/16-64Kbps(AAC)/8-320Kbps(MP3) Network Simultaneous Live View Up to 6 channels API Open Network Video Interface (PROFILE S, PROFILE G), ISAPI, SDK, ISUP Protocols TCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, HTTPS, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, SMTP, 802.1x, SSL/TLS, PPPoE User/Host Up to 32 users 3 levels: Administrator, Operator and User Network Storage Supports microSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Web Browser Plug-in required live view: IE 10, IE 11 Local service: Chrome 57.0+, Firefox 52.0+ Image Day/Night Switch Day, Night, Auto, Schedule Image Enhancement BLC, HLC, 3D DNR Image Settings Mirror, saturation, brightness, contrast, sharpness, AGC, and white balance adjustable by client software or web browser Privacy Mask 4 regions of privacy masks Interface Built-in Microphone Yes On-board Storage Built-in micro SD/SDHC/SDXC slot, up to 256 GB Hardware Reset Yes Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port Smart Feature-Set Basic Event Motion detection, video tampering, exception General Linkage Method Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture Web Client Language 33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian General Function Anti-flicker, password protection, password reset via email Software Reset Yes Storage Conditions -30 C to 60 C (-22 F to 140 F). Humidity 95% or less (non-condensing) Startup and Operating Conditions -30 C to 60 C (-22 F to 140 F). Humidity 95% or less (non-condensing) Power Supply 12 VDC 25% PoE: 802.3af, Type 1 Class 3 Power Consumption and Current 12 VDC, 0.4 A, max. 5 W PoE (802.3af, 36 V to 57 V), 0.20 A to 0.1 A, max. 6.5 W Power Interface O 5.5 mm coaxial power plug Camera Material Aluminum alloy body Camera Dimension O 110 81.25 mm (O 4.33" 3.20") Package Dimension 150 150 141 mm (5.9" 5.9" 5.6") Camera Weight Approx. 390 g (0.9 lb.) With Package Weight Approx. 656 g (1.4 lb.) We accept payment by Paypal, all major Credit card, Debit Card. Please make sure to leave item number with payment. If any special requirement needs, please leave a note while check out. Payments are expected within 7 days after the last winning auction is closed. Unpaid item (UPI) complaint will be filed with upon non-receipt of payment. Bidding on multiple auctions? Simply wait until all of the auctions have ended, and complete the checkout from the most recent email that you received from us. Once you have completed the checkout, you will not be able to combine any additional auctions. We start to process and rush your order once checkout is completed with payment. We are required to collect 8.25% Texas sales tax when Ship-To address is in Texas. We ship worldwide from United State. Most order ship in same day by 4pm central time on business day only. Please make sure the Ship-To address you input during checkout is correct. We are NOT responsible for any wrong or undeliverable addresses. Tracking number will be send to your email once the item shipped. Shipping and handling rates shown on Shipping and Payments detail section apply to 50 US States, Puerto Rico, APO and FPO addresses and other US territories with a valid US zip code. note: APO/FPO or any military address are not eligible for delivery confirmation due to postal restriction. We also charge flat rate S H for International shipment; however it may vary from country to country. Please select your country in the Shipping and Payments detail section for the rate to your country. Business Hour 9:00Am to 5:30Pm (Monday to Friday) Central Time. We try our best to answer your questions less than 4 Business Hours. Otherwise we will response your email within 1 day. We are aware that the communication problems between the seller and the buyer could be frustrating if left unresolved. We would like to let you know that we will respond to all after-sale questions based upon our knowledge. If you asked a question and did not get any response in 1day, please try again, and if you still did not get any response in the next 2 days, it could be either that we do not receive your emails or you do not get our email answers. In this case, please check your email server, email address quotas and/or spam email folder and try again, and if you still do not get any response, please call us at contact number in contact us page during the business hour. Please be ready your ID and item number before you call. Please keep all material including shipping label for return. All item has been tested before we ship out. So you will not receive defective item. Money Back Guarantee and Replacement Warranty terms start from the date you receive the item. Physically damaged items cannot be returned. If you receive a DOA (Dead on Arrival) item, please contact us within 14 days. Returns/Exchanges will not be accepted unless authorization has been issued Customer Service Department. To receive an RMA (Returns Merchandise Authorization) number please send an email to with a copy or the original invoice and return form. For more information about return policy. Please review our Return Policy page location on the bottom of the page. Chili Inc. All rights reveserved. Chili, the Chili logo are trademarks or registered trademarks of Chili Inc.
