The AEGIS SGR-0.625-UKIT-1A4 Bearing Protection Split Ring is a premium grounding solution engineered to prevent electrical discharge damage in motor bearings. Designed for 5/8" (0.625") shafts typically found in NEMA 56 frame motors, this split-style ring ensures reliable protection by diverting harmful shaft currents safely to ground. The split-ring design allows for easy installation without disassembling the motor, making it ideal for both new and retrofit applications. Key Features Split-ring design for simple, non-invasive installation Protects bearings from electrical fluting and pitting Optimized for 56 frame motors with 5/8" shaft Reduces maintenance costs and extends motor service life Compatible with VFD-driven motors Maintenance-free operation with long-lasting performance Includes universal mounting hardware and conductive grease Specifications Part Number: SGR-0.625-UKIT-1A4 Brand: AEGIS Type: Bearing Protection Split Ring Shaft Diameter: 5/8" (0.625") Motor Frame: NEMA 56 Material: Conductive microfibers with aluminum housing Application: Shaft grounding for motors powered by variable frequency drives (VFDs) Installation: Split design for field retrofit without removing couplings or bearings Compatible Models: Suitable for 5/8" shaft (56 frame) motors from leading manufacturers such as Baldor, Marathon, Leeson, WEG, and ABB ? and more. Why Choose This Item Select the AEGIS SGR-0.625-UKIT-1A4 to ensure maximum bearing protection, quick installation, and extended motor life. Its split design offers unmatched convenience for retrofitting existing motors, while AEGIS?s proven grounding technology keeps your system running smoothly and efficiently in any industrial or commercial environment.
