JBL C29AV-WH-1 Premium Indoor Outdoor Monitor Speaker Overload Protection The Control 29AV-1 provides improved voicing for extremely flat, high fidelity performance, extended bandwidth and well-controlled defined coverage from a compact loudspeaker. Features Extended bandwidth, extremely smooth frequency response. 110 x 85 HF coverage, rotatable horn. 110 W transformer for 70 V or 100 V lines, with 8 ohm thru. SonicGuard? overload protection. 200 mm (8 in) Kevlar cone woofer, 25 mm (1 in) titanium diaphragm compression driver. Includes InvisiBall? mounting hardware, plus ten 6 mm attachment points for suspension and optional U-bracket. Sealed input panel cover and screwdown input terminals. Specifications Frequency Range: 37 Hz ?18 kHz (-10 dB) Power Capacity: 300 W Continuous Program Power; 150 W Continuous Pink Noise Transformer Taps: 70 V: 110 W, 55 W, 28 W 14 W 100 V: 110 W, 55 W, 28 W, Thru Position: 8 ohms nominal Frequency Response: 45 Hz ? 18 kHz ( 3 dB) Maximum SPL (1m): Short-Term: 120 dB; Long-Term: 114 dB Nominal Sensitivity: 90 dB (2.83V / 1m) Coverage Angle: 110 H x 85 V, rotatable Directivity Factor (Q): 7.2 dB, averaged 500 Hz to 16 kHz Directivity Index (DI): 8.6 dB, averaged 500 Hz to 16 kHz Impedance: 8 ohms Minimum Impedance: 6.3 ohms @ 230 Hz Crossover Network: 3rd order High Pass, 2nd order Low Pass with impedance compensation, 2.5 kHz crossover frequency Drivers: LF: 200 (8 in) kevlar cone with pure butyl rubber surround, 50 mm (2 in) voicecoil on fiberglass former HF: 25 mm (1 in) compression driver, pure titanium diaphragm with patented JBL diamond surround Enclosure: High impact polystyrene Grille: Thermoset composite coated steel, WeatherMax multi-layer foam Overload Protection: Full-range power limiting to protect network and transducers. Serviceable internal fuse to protect during exceptional overload conditions. Outdoor Capability: IEC 529 IP-X4 rating. Exceeds Mil Spec 810 for humidity, salt spray, temperature UV. Passes Mil-Std-202F for salt spray. Input Connectors: Screw-down terminal strip, zinc plated copper base, nickel plated metal screws/washers. Accepts up to 9 mm outside 4 mm inside open lug (#6, #8 or #10 lug), plus bare wire (up to 12 AWG/2.5 mm2). Safety Agency Transformer is listed per UL1876 Colors: White Dimensions (H x W x D): 520 x 306 x 277 mm (20.5 x 12.0 x 10.9 in.) Net Weight (each): 12.2 kg (26.8 lb.) Included Accessories: 1 pc MTC-PC2 input panel cover, InvisiBall mounting base, 6 mm x 260 mm InvisiBall Hex wrench. ---------------------------------------------------------------------------------------------------------------- Echotone Music LLC is an experienced long time E-commerce Audio Musical instrument dealer since 1998. We take pride in selling quality gear for musicians, sound engineers, production companies and broadcast applications. Shipping --Items are well packed and shipped USPS, UPS or Pallet Freight Service. Items purchased on Friday may not ship until Monday or until the projected processing period. We are working hard to get your unit Built ( if needed), processed and shipped. Returns/Refunds- If there is truly a manufacturing defect a return tag will be provided, otherwise customer pays for return shipping costs. Returned items must be sealed/unopened in original, brand-new condition, showing no signs of wear or use such as mount marks, plug marks, scratches, scuffs, dings or scrapes, screw mount marks or collateral material damage.. Items must also include all original packaging, manuals, warrantees accessories or your return may be subject to a return handling charge. Refunds or for the Item cost only. If the item was listed as free shipping then the cost of the shipment will be deducted from the units original cost. Gear returned with out all its original packaging, warranty cards and accessories or that shows signs of wear from use, will be subject to an additional service fee. This item is now used and it would be unfair to resell to another customer as new. The following products cannot be returned - Clearance items, Custom Builds, items identified as non-returnable, discontinued items, used or NOS items, electronic software downloads, demo gear, strings, reeds, computers, tubes, earbuds, earplugs, recorders, harmonicas, raw-frame speakers, drumheads, drumsticks, turntable cartridges, fog fluids, clothing/footwear, cleaners, polishes polishing cloths, software/soundware, books, CDs, DVD's, vinyl records, and videos. Happy customers, that's music to our ears!
