this document describes valueram s 1g x 64-bit (8gb) ddr3l-1600 cl11 sdram (synchronous dram), 2rx8, low voltage, memory module, based on sixteen 512m x 8-bit fbga components. the spd is programmed to jedec standard latency ddr3-1600 timing of 11-11-11 at 1.35v or 1.5v. this 204-pin sodimm uses gold contact fingers. the electrical and mechanical specifications are as follows: features: jedec standard 1.35v (1.28v ~ 1.45v) and 1.5v (1.425v ~1.575v) power supply vddq = 1.35v (1.28v ~ 1.45v) and 1.5v (1.425v ~ 1.575v) 800mhz fck for 1600mb/sec/pin 8 independent internal bank programmable cas latency: 11, 10, 9, 8, 7, 6 programmable additive latency: 0, cl - 2, or cl - 1 clock 8-bit pre-fetch burst length: 8 (interleave without any limit, sequential with starting address 000 only), 4 with tccd = 4 which does not allow seamless read or write [either on the fly using a12 or mrs] bi-directional differential data strobe internal(self) calibration : internal self calibration through zq pin (rzq : 240 ohm 1%) on die termination using odt pin average refresh period 7.8us at lower than tcase 85 c, 3.9us at 85 c tcase 95 c asynchronous reset pcb: height 1.18 (30mm), double sided component cl (idd) 11 cycles
