YUCHENGTECH Woodworking Edge Bander Banding Machine Portable Edge Bander Curve Straight Edge Banding Machine With Speed Control 5 10m/min (110V Adjustable speed) 1. Glue uneven on the banding tape 1.Incomplete melting of hot melt glue. ---Open the melting pot cover to check the hot melt glue. 2.Insufficient glue. --Adjust gluing knob. 3.The bending stripdeformated. --Replace a better edge banding tape. 2. Poor adhesion of the banding tape 1.Non parallel adhesive veneer. --Re-calibratethe support plate(see manual) 2.Heating for a long time, hot melt glue is deteriorated. --Change hot melt glue 3.Hot melt glue temperature is not the correct temperature. --Adjust the temperature. 3. Banding tape is not in level Twist strake attached starting point/push slower than the speed. --The support plate should be flush with the workpiece when pressing and fit the starting point, the edge to the workpiece, can not loose. 4. Electric start abnormal Hot melt glue not yet dissolved ---Need to re-adjust the temperature, and then start running. 5. Banding tape is not moving Wheel or feed wheel skid --Clean the belt pulley and the feed wheel. 1.Advantages: More suitable for sealing edges of different shapes, finer and shorter edges. It can seal straight edge, curve, outer arc, inner arc and circumference (arc radius 20mm or more), and the length of the frame is not limited. 1.CharacteristicPortable edge banding machine, small size, light weight, can carry edge banding, can also be in desktop. 2.Characteristic: Portable edge banding machine, small size, light weight, can carry edge banding, can also be in desktop. Free from time and space constraints, it can be operated anytime, anywhere. 4.Important parameters: The speed can be adjusted. Edge sealing speed: 5 10 m / min; Edge band width: 16-40mm; Gluing method: double side gluing; Heating time: 5 10 minutes; Rubber pot capacity: 1000ml. 5.Applications: Suitable for all kinds of plates and edge strips, such as: ABS, PVC, particle board, melamine board, fine wood board, MDF, integrated board, acrylic board, etc.
